Motor Starter, 12 - 18 Amp, 120V Coil, 3 HP 240V 1PH

Complete motor starter sized for Lightly or Normal loaded 3 HP at 240V, 1PH, Single Phase. Operating Voltage is 120VAC.

The pictures may show a unit slightly different than the specifications. Use the specifications - not the pictures.

Shipped as two separate devices, contactor and overload.

LSis brand, made in Korea

• Contactor - Nema size 1, IEC size 18
• Overload - Class 10 differential type, phase failure protection
• Coil - 120V
• Contactor HP rating UL - 3 HP @ 240V, 1PH, Single Phase
• Overload trip range - 12 - 18 Amps
• Sized for Lightly or Normal loaded 3 HP at 240V, 1PH, Single Phase
• Includes (1) N/O auxiliary contact built in the contactor
• Overload frame size 12
