Motor Starter, 100-160 Amp, 230V Coil, 50 HP at 208-230V 3PH, IEC Size 225
Stock:
In Stock
Complete motor starter sized for Normal or Heavy loaded 50 HP at 208-230V 3PH. Operating Voltage is 208-240V.
Contactor, IEC size 225. Overload Frame size 225. Heavy duty set up. Elimia PN: 100-160-230-225
Complete motor starter sized for a Normal or Heavy loaded 50 HP at 208-230V 3PH. Operating Voltage is 208-240V.
The pictures may show a unit slightly different than the specifications. Use the specifications - not the pictures.
Shipped as two separate devices, contactor and overload.
LSis brand, made in Korea
- Contactor - IEC size 225
- Overload - Class 10 differential type, phase failure protection
- Coil - 230V
- Contactor HP rating UL - 60HP @ 208V, 75HP @ 230V 3PH
- Overload trip range - 100-160 Amps
- Sized for Normal or Heavy loaded 50 HP at 208-230V 3PH
- Includes (2) N/O & (2) N/C auxiliary contact
- Overload Frame size 225
