Motor Starter, 80-105 Amp, 230V Coil, 30HP 208V, IEC Size 130
Stock:
In Stock
Complete motor starter sized for Normal or Heavy loaded 30HP at 208V. Operating Voltage is 208-240V..
Contactor, IEC size 130. Overload Frame size 150. Heavy duty set up. Elimia PN: 80-105-230-130
Complete motor starter sized for a Normal or Heavy loaded 30HP at 208V. Operating Voltage is 208-240V.
The pictures may show a unit slightly different than the specifications. Use the specifications - not the pictures.
Shipped as two separate devices, contactor and overload.
LSis brand, made in Korea
- Contactor - IEC size 130
- Overload - Class 10 differential type, phase failure protection
- Coil - 230V
- Contactor HP rating UL - 40HP @ 208-230V, 3PH
- Overload trip range - 80-105 Amps
- Sized for Normal or Heavy loaded 30HP at 208V
- Includes (1) N/O & (1) N/C auxiliary contact
- Overload Frame size 150
